Feature :

- Configurable ranges from 0 to 5000 ppm* and from 0 to 50 °
- 4 wires analogue output 0-5/10 V or 0/4-20 mA
- Power supply 24 Vdc/Vac or 230 Vac (optional 115 Vac)
- Trend indicator
- ABS V0 IP65 housing, with or without display
- “¼ turn” system mounting with wall-mount plate

TECHNICAL FEATURES IN TEMPERATURE
Measuring range
From 0 to +50 °C
Unit of measurement
°C / °F
Accuracy*
±0.3°C
Response time
T90 = 0.9 second for Vair = 1 m/s
Resolution
0.1 °C
Type of sensor
NTC
Type of fluid
Air and neutral gases

TECHNICAL FEATURES IN CO2
Measuring range
From 0 to +5000 ppm
Other available range : from 0 to 20 000 ppm
Unit of measurement
ppm
Accuracy*
From 0 to 5000 ppm : ±3% of the measured value ±50 ppm
From 0 to 20 000 ppm : ±5% of the measured value ±100 ppm
Response time
T63 = 35 s
Resolution
1 ppm
Type of sensor
Infrared sensor
Type of fluid
Air and neutral gases
