▪ Parameteres     Range       Resolution

   1. O2       : 0 - 25%       0.2%

   2. CO       : 0 - 20.000 ppm   ±5 ppm

   3. NO        : 0 - 2000 ppm     1 ppm

   4. SO2     : 0 -2000 ppm     1 ppm

   5. NO2     : 0 - 1000 ppm     1 ppm

   6. CO2     : 0 - 25%   (calculated)

▪ Processing of measuring data

   - All results shown on display

   - Averaing time : 2, 10, 20, 30, 60, 120, 180 seconds

   - Graphical presentation of all measured values as diagram

   - Storage for 32 measurements - "measure now, print later"

   - Powerful PC program for analyzer settings and data comm

▪ Software capabilites

   - Automatic zeroing when the analyser is switched on

   - All settings for the flue gas analyzer carried out with PC prog.

   - List of 6 common fuels (from DIN or OENORM)

   - 4 further freely programmable fuels

   - Permanent automatic check of the instruemnt with acoustic

     warning and full information in the "control list"

▪ Probe Heated, with condensate trap and filter

▪ Probe length 300 mm, 800⁰C

▪ Length of gas line 2 m

▪ in-line, Filter 20 μm

▪ Gas pump Membrane pump

▪ Display LCD graphic display 36 x 66 mm

▪ Power supply mains adapter or internal rechargeable battery (24 h)

▪ interface, RS232C for external computer communication and IR

  connection for external printer

▪ Clock/calender, integrated

Informasi Harga:

a. Sensor O2, CO + Complete Unit

b. Sensor O2, CO, NO + Complete Unit

c. Sensor O2, CO, NO, NO2 + Complete Unit

d. Sensor O2, CO, NO, SO2 + Complete Unit
